Yamaha Motor Co., Ltd. will introduce the CELL HANDLER2 in March 2025
Yamaha Motor Co., Ltd. will introduce the CELL HANDLER™2 in March 2025! Following the footsteps of the previous model, the CELL HANDLER™2 is the next-generation cell handling system – the integration of Yamaha’s innovative high-precision technologies and AI and other new technologies, all shaped by invaluable feedback from researchers. The AI-integrated auto functions, expanded imaging functions, and improved user experience – each aspect of the CELL HANDLER™2 is designed to empower researchers in their pursuit of science. Whether your needs in your drug discovery and development are in large-scale screening, cell quality control, or cell line development, the CELL HANDLER™2 is your perfect partner that accelerates your cell research.
New Product Introduction Video
Three Features
More Imaging Options & Improved Auto Image Recognition
The imaging functionalities have been upgraded with additional observation options, such as 20x bright field observation, 4x and 10x phase contrast observation, and a video recording mode. Two fluorescence filter options have also been added – now available in five colors – giving researchers more detailed cell data than ever before. That is not all. The new auto-focus function automatically detects the height of the target cell, requiring less image data volume and reducing researchers’ invaluable time and effort. And with its expanded functions as a microscope, the CELL HANDLER™2 can be used in day-to-day cell observation as well as image acquisition during cell picking. These enhanced imaging options will open new possibilities in your research.
Advanced AI-integrated Analysis Software
The Cell Handler™2 software is designed to allow the implementation of various AI models. Based on your teaching data, the CELL HANDLER™2 accurately identifies the contours of cells that meet your desired conditions. The AI-based learning functionality optimizes target cell profiles for each customer. Accurate detection of cells that were previously difficult to achieve will increase research efficiency and improve the reliability of your experiments.
Traceable Cell Handling with More Flexibility
The operation of the CELL HANDLER™2 has become even easier than ever before with a more intuitive user interface. The information on cell positions and conditions are stored before and after cell picking, maintaining high traceability. Cell handling has also become more flexible, satisfying wider research needs. Combined with its intuitive user interface, the Cell Handler™2 is your perfect companion in the pursuit of research.
Basic Specifications
*Specifications and appearance are subject to change without notice due to improvements etc.
| Model Name | CELL HANDLER™2 | ||||
|---|---|---|---|---|---|
| Dimensions | L 1350 × W 900 × H 1600 (mm) | ||||
| Weight | Approx. 550kg | ||||
| Power supply | Power supply: Single-phase AC 100 - 120 V / 200 - 230 V (-10% to +8%) Frequency: 50Hz/60Hz Transient overvoltage: overvoltage category level II or lower Temporary overvoltage of the main power supply: 2.5 kV or lower Power consumption: Average approx. 690W / Max approx. 990W Installed capacity: 1.2 kVA |
||||
| X, Y, Z axes | AC servo motor | ||||
| Operation control system | Touch panel display, mouse with optical wheel, mini keyboard | ||||
| Memory device | Built-in 8TB HDD | ||||
| External interface | Device front: USB 3.0 x 4 | ||||
| Camera | CMOS 2048 x 1544 pixels | ||||
| Optical lenses | Bright field observation: 4x, 10x | ||||
| Light source | LED | ||||
| Sterilization lamp | UV 15W x 2 | ||||
| Air cleaning unit | HEPA filters x 2 | ||||
| Environmental conditions | Usage site: Inside the building
- There must be no dirt, dust, or corrosive gas - The instrument must not be exposed to strong indoor lighting or direct sunlight as it may adversely affect the imaging processing - The instrument must be installed on a level concrete floor with a load-bearing capacity of at least 4900 N/m² |
||||
| High magnification system | 20x objective lens Phase contrast: 4x, 10x | ||||
| Fluorescence system | LED light source for fluorescence observation 3 to 5-color fluorescent filters |
Note 2: Specifications and appearance are subject to change without prior notice for improvement purposes.
Note 3: The above information is based on our internal evaluations. Results may vary depending on the work environment, cell type, and other factors.
